Camera Digital Dry Cabinet Constant / humidity dehumidification box

Camera Digital Dry Cabinet Constant / humidity dehumidification box

  • Camera Digital Dry Cabinet Constant / humidity dehumidification box
  • Camera Digital Dry Cabinet Constant / humidity dehumidification box
  • Camera Digital Dry Cabinet Constant / humidity dehumidification box
  • Camera Digital Dry Cabinet Constant / humidity dehumidification box
Camera Digital Dry Cabinet Constant / humidity dehumidification box
جزئیات محصول:
محل منبع: R.P. of China
نام تجاری: SOPERSL
گواهی: CE.SGS
شماره مدل: DC814363-4LE
پرداخت:
مقدار حداقل تعداد سفارش: 5
قیمت: USD900-1900
جزئیات بسته بندی: PAPER BOX
زمان تحویل: 10-15DAYS
شرایط پرداخت: TT,LC AT SIGHT
قابلیت ارائه: 1000PCS/MONTH
مخاطب
توضیحات محصول جزئیات
Material: Metal Color: Black or White
Function: Drying proof Style: Vertical
Cabinet Size: 1200mm(W)x710mm(D)x1910mm(H) Standard: IPC/JEDEC J-STD-033B
برجسته:

digital dry cabinet,wonderful dry cabinet

,

wonderful dry cabinet

Camera Digital Dry Cabinet Constant / humidity dehumidification box


Applications:



DC814363-4LE is equipped with a precise LED control, which has ±3%RH precision tolerance. It is especially designed with fully automatic humidity control at <10%RH to prevent any kinds of moisture damages. This cabinet is the perfect storage for SMT/BGA/PCB/LED components. The newly innovated design greatly increases dehumidifying system runs faster and more powerful compare to those of traditional dry cabinets. Hence, it decreases the defective rate at production line at the same time.

Main Specifications of DC814363-4LE LED CONTROL HUMIDITY DESICCANT CABINET

DC814363-4LE -LED CONTROL HUMIDITY DESICCANT CABINET
1436-Litre (RH:1-10%For SMT,IC,BGA,copper,siler,silver plating components)

5 Shelves (Adjustable), ,Each with 150kg loading
4 doors, Manual
Ext. Sizes W×D×H(mm/in): 1200×710×1910/ 47.2×28×75 in
Int. Sizes W×D×H(mm/in): 1198×682×1723mm/ 47.1×27×68 in
Weight: 147Kgs/ 323 lbs



  • Cabinet Size: 1200mm(W)x710mm(D)x1910mm(H)
  • Equipment with high performance, reliable desiccators and himidity controller located at the lower deep inside.

  • Display Precision Tolerance: ±1°C, ±3%RH

  • Cabinet Structure: 1mm thickness cold steel with antistatic paint, 1.2mm cold rolled plate.

  • Doors/windows: Handles, airtight magnetic sealers and temper glass.

  • Lock: Zinc alloy lock with plus pressure capability.

  • High intensity truckle with brake, 4 antistatic 3” wheels, 2 of them with brakes.

  • Power Consumption: Ave. 60W; Max. 420W

  • ROHS certification surface powder coating

  • Standard: IPC/JEDEC J-STD-033B



Market Segments

  • SONY
  • 3M
  • SIEMENS
  • IBM
  • TOSHIBA
  • SUMSUNG
  • NIKONAND SO ON


Our Advantage

  •  High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience



Drying Cabinet Picture  details

Digital Temp Display &  RH Control
 Camera Digital Dry Cabinet Constant / humidity dehumidification box 0

 US-Made Honeywell sensor



Professional dehumidifier Host

Camera Digital Dry Cabinet Constant / humidity dehumidification box 1 Modular Dehumidification system: Can be changed quickly,easy maintenance.



Instroduction



With over than 10 years of experiences in Humidity Control Solution, SSL desiccators is especially designed and made to comply with J-STD-033/IPC.

Not only do we focus on the performance of our products, we also incorporate Environmental Friendly design to all of our drying boxes and have helped out many reputable SMT / IT customers cutting their product defective rate to zero, and substantially saving them worth of hundred and thousands US dollars each year.



Low Humidity Drying cabinet Package


Plastics bag-PE around-carton box OR crate box


Competitive Advantage:



Energy saving design: low electricity consumption resuegence, no heating, no condensation Dripping, absence of fan noise

Dual digital hygrometer-Ecology Design

Noisy free, vibration free, low humidity keeping at ambient temperature and long-term consecutive driving.

Energy saving design: maintenance cost is only a very little electricity. It comes with humidity controller.

No expendable supplies (Exchange free desiccant), very economical.

No use of batteries for hygrometer.

Long lasting and highly reliable.

With detachable shelves, wide space is available to use.

With high technology( photocatalyst, IC timer, shape-memory alloy and dual digital hygrometer)





Do you know Moisture damamges?

In general, most molds grow when humidity is higher than 60%RH. Dehumidifying Dry Cabinets are useful in preventing mold from growing.

However, normal dry box storage cannot prevent the particular type of mold which grows under 20%RH. To protect your cameras from the general to particular molds, SSL Dry 01 series dry cabinets are the appropriate choice. There are three levels of humidity setting dial in 01 series cabinets; "High (50%)", "Standard (40%)" and "Low (30%)". Set the dial at the standard mode (40%) for the ideal humidity level to keep your camera lens from various molds.



Best Storage Condition(%RH) for Different Material

TYPE

Best Storage  Condition(%RH)

      Moisture Sensitive Material

TYPE 01

30%-50%RH

Optical,Photographic and Media Field: Lenses, Cameras, Microscopes ,Telescopes, Binoculars, Video cameras, Video tapes, Infrared cameras, Prism for lasers, Optical measurements apparatus, Films, Microphotographs, Picture films, CD/DVD, Microphone, Musical instruments,etc

Paper Products,  Art and Medicinal Field: Printed matter, Label, Ancient documents, Cultural assets, Art, Industrial art, Excavated articles,stamp,medicinal materials,coffee,cigarette etc.

Semiconductors, Electronics Parts and Precision Instrument and Parts Field: Semiconductors, IC packages, Condensers, Resistances, PCB, Wafers, Filament, Lithium, Nickel batteries, Crystal oscillators, Gauges, Weight, Hygroscopic plastics, Metal, Non-ferrous metal, Welding rods, Metal powdery product, Ultrafine powdery alloy.

TYPE 02

30%-10%RH



Semiconductors, Electronics Parts and Precision Instrument and Parts Field: Semiconductors, IC packages, Mesuring tools,Electronic component,such as IC,BGA,etc.

TYPE 03

10%RH below



Semiconductors, Electronics Parts and Precision Instrument and Parts Field: Semiconductors, IC packages, Condensers, Resistances, PCB, Wafers, Filament, Lithium, Nickel batteries, Crystal oscillators, Gauges, Weight, Hygroscopic plastics, Metal, Non-ferrous metal, Welding rods, Metal powdery product, Ultrafine powdery alloy.





Model

Door type

Overall Size H×W×D(mm)

Interior size H×W×D(mm)

Sheet

Capacity(L)

Voltage

Average Power(W)

N.W.
(KG)

DC8983L

1,manual

688×488×400

598×446×372

1

98

85V-265V
50Hz/60Hz

18

20

DC81603L

1,manual

1313×598×400

1151×596×372

3

160

85V-265V
50Hz/60Hz

18

31

DC82403L

1,manual

1310×598×400

848×596×372

3

240

85V-265V
50Hz/60Hz

18

43

DC85403L

1,manual

1310×598×710

848×596×682

3

540

85V-265V
50Hz/60Hz

40

70

DC87183L

1,manual

1910×598×710

1723×596×682

5

718

85V-265V
50HZ/60HZ

40

85

DC83203L

2,manual

1010×900×450

848×898×422

3

320

85V-265V
50HZ/60HZ

20

54

DC84353L

2,manual

1010×900×600

848×898×572

3

435

85V-265V
50HZ/60HZ

20

60

DC88703L

2,manual

1895×900×600

1700×898×572

3

870

85V-265V
50HZ/60HZ

40

106

DC814363L-6

6,manual

1910×1200×710

1723×1198×682

5

1436

85V-265V
50HZ/60HZ

80

147

DC814363L-4

4,manual

1910×1200×710

1723×1198×682

5

1436

85V-265V
50HZ/60HZ

80

147
